Apollo Hi-Lo Automatic Temperature Controller Cabinet, 34HL, Stainless Steel, Flush Lock

Product Image for Apollo Hi-Lo Automatic Temperature Controller Cabinet, 34HL, Stainless Steel, Flush Lock
Product Image for Apollo Hi-Lo Automatic Temperature Controller Cabinet, 34HL, Stainless Steel, Flush Lock

group: 34HLBOX01

The Apollo 34HL Series Automatic Temperature Controller / HI-LO meets the new ASSE 1069 standard for multiple shower applications and the ASSE 1017 standard for point of source distribution applications. The device provides consistent temperature control to flow as low as 0.5 GPM. The MVHL is capable of low flow control without need for recirculation pumps and higher flow with parallel installation. Integral strainers and check valves are supplied at the valve inlets for added protection and long term performance.
  • US Patent 6,929,188 B2
  • Union Isolation Ball Valve Connections
  • Corrosion Resistant Bronze Construction
  • Multiple Cabinet Options
  • Integral/Replaceable In-Line Check Valves
  • Integral/Replaceable In-Line Strainers
  • Hi-Lo Flow Calibration Valve
  • Pressure Gauges (0-160 psi)
  • Temperature Gauge (0-200°F)
  • Cold & Hot Water Protection Failure
  • Independent Low & High Flow Temp Control
  • Made in USA - ARRA compliant
read more
read less
if the download did not start automatically, click here

PDF generation failed, please try again later

applications

heating

heating

show all
show less

segments

commercial building

commercial building

show all
show less

approvals

no approvals available

item number

size

dimensions

weight

packaging

gtin

item number

34hlbox01

size

1-1/4" (DN32)

dimensions

-

weight

14.52 kg

packaging

carton (1 pce)

gtin

00670750920394

item number

size

item number

34hlbox01

size

1-1/4" (DN32)

technical drawing for product

characteristics

materials

finishing

none

general

product group

valves (mixing valves)

ETIM class

EC011516 Thermostatic flow control valve, hot tap water

brand

Apollo

series

34 Series Mixing Valves

type

34HLBOX01

image for 34HL-100 Image

image | png

34HL-100 Image

image for 34HL-100 Diagram

diagram | png

34HL-100 Diagram

submittal sheet | pdf

34HL-100 Submittal Sheet
