group: 1065PT
potable water
heating
cooling
commercial building
industry
WRAS
item number
size
dimensions
weight
packaging
gtin
item number
size
G1 1/4
dimensions
30x65x145 mm
weight
0.95 kg
packaging
-
gtin
05022050400116
item number
size
G1 1/2
dimensions
30x70x155 mm
weight
1.14 kg
packaging
-
gtin
05022050402752
item number
size
d1
DN1
l1
z1
slw1
d2
DN2
l2
z2
slw2
M
H
Y
V
U
a
item number
202052size
G1/2
d1
31.0
DN1
DN15
l1
23
z1
14
slw1
31
d2
31.0
DN2
DN15
l2
23
z2
14
slw2
20
M
55
H
70
Y
15
V
29
U
26
a
90
item number
202053size
G3/4
d1
38.0
DN1
DN20
l1
24
z1
14
slw1
38
d2
38.0
DN2
DN20
l2
24
z2
14
slw2
20
M
55
H
80
Y
16
V
34
U
33
a
90
item number
202054size
G1
d1
46.0
DN1
DN25
l1
29
z1
18
slw1
46
d2
46.0
DN2
DN25
l2
29
z2
18
slw2
21
M
64
H
95
Y
19
V
41
U
41
a
90
item number
202055size
G1 1/4
d1
59.0
DN1
DN32
l1
32
z1
19
slw1
59
d2
59.0
DN2
DN32
l2
32
z2
19
slw2
26
M
77
H
115
Y
19
V
57
U
49
a
90
item number
202056size
G1 1/2
d1
65.0
DN1
DN40
l1
35
z1
21
slw1
65
d2
65.0
DN2
DN40
l2
35
z2
21
slw2
26
M
86
H
125
Y
20
V
65
U
55
a
90
item number
202057size
G2
d1
80.0
DN1
DN50
l1
43
z1
22
slw1
80
d2
80.0
DN2
DN50
l2
43
z2
22
slw2
31
M
95
H
155
Y
25
V
88
U
67
a
90
color
brass
materials
brass (CW617N)
finishing
none
shape
straight
connection type
G - female thread gas cylindrical (BSPP)
pressure rating (PN)
PN 16
sealing
NBR (Nitrile)
product group
valves (gate valves)
ETIM class
EC010163 Gate valve
HS code
84818069
brand
Pegler
series
Gate Valve
type
1065PT
UNSPS
40141613
max operating pressure liquid
17.5 bar
min. medium temperature
-10 Ā°C
max medium temperature
85 Ā°C
peak medium temperature
85 Ā°C
Kvs-value
value depends on the item view items
label
value
label
ETIM class
value
label
Housing material
value
Brass
label
Material quality
value
CuZn40Pb2 (CW617N)
label
Connection 1
value
Internal thread cylindrical BSPP-G (ISO 228-1)
label
With coupling connection 1
value
No
label
Connection 2
value
Internal thread cylindrical BSPP-G (ISO 228-1)
label
With coupling connection 2
value
No
label
Article compression class
value
PN 16
label
Flange compression class
value
PN 16
label
FM quality mark
value
No
label
UL quality mark
value
No
label
ULC quality mark
value
No
label
LPCB quality mark
value
No
label
Medium temperature (continuous)
value
-10Ā°C - 85Ā°C
label
Medium temperature (continuous) (imperial)
value
14Ā°F - 185Ā°F
label
Surface protection
value
Untreated
label
Operation
value
Hand wheel
label
With position indicator
value
No
label
Spindle and/or hand wheel rising
value
No
label
With waste fitting
value
No
label
VdS quality mark
value
No
label
KIWA certified
value
No
label
Gastec QA mark
value
No
label
Gastec QA - AR 214 (H2)
value
No
